The SuperNova is our most versatile platform for mapping with
flight times up to 1.5hrs and a large payload capacity. It carries payloads as light
as the Gopro Hero up to the 1.7lbs Tetracam MCA, a six lens multispectral camera
ideal for precision agriculture.
The same interface and functionality that
is present in our Robota Ground Control software [ https://sellercentral.amazon.com/dp/B00BECGKY8
] extends to the SuperNova. The GCS lets you enjoy stress free operation, insert
search patterns that automatically set the desired image overlap. One click automated
takeoff and precision landing make operating the SuperNova as easy as playing a
computer game. Set waypoints, search patterns, and orbits with the click of a mouse.
Applications: The SuperNova is currently used in the following applications:
Precision Agriculture
Geology
Topography
Photogrammetry
Forestry
Research
Search and Rescue
Live Video Surveillance
Wifi repeater
Performance:
The SuperNova's endurance ranges from 100 to 70 minutes
depending on the payload selected. The vehicle takes off on wheels or via hand launch.
No special launching equipment is required. A 2lb maximum payload carying capacity
opens the doors for a wide variety of applications. A list of specifications can
be found here [ http://data.robota.us/docs/SuperNovaSpecs.pdf ].
Specifications:
Flight time, 50 to 90minutes /li>
Speed range, 21kts to 39kts
Max wind speed, 29kts
Weight, 4.5 lbs without payload
Wing Span, 64 in
Length, 46 in
Payload bay, 5 x 4 x 3 inches. 2lb Max
TTransports in a 40 x 18 x 8inch box
Support Services:
Reintegration Service /li>
Training
Software Maintenance and Support Subscriptions
Lifetime email support for complete system
Downloads:
Radio Drivers - Windows 32/64bit [ http://data.robota.us/files/USBDrivers.zip
]
